Welded Stainless Steel U Bent Tube Bending EN 1.4301 1000mm

Ask Lasest Price
Brand Name :	ZHE HENG
Model Number :	EN 1.4301，ASME S30400
Certification :	BV, PED, ISO9001
Price :	$1000-4200/Ton
Payment Terms :	L/C, T/T, D/P, D/A
Supply Ability :	1000+
Delivery Time :	100TONS/30-45 work days

Add to Cart

Product Details
Company Profile

Welded Stainless Steel U Bent Tube Bending EN 1.4301 1000mm

Product Description

Overview:

Stainless steel shaped pipes are widely used in various structural parts, tools and mechanical parts. Compared with the round pipe, the stainless steel shaped pipe generally has a larger moment of inertia and section modulus, and has a larger bending and torsional resistance, which can greatly reduce the weight of the structure and save steel.

Specification:

Approximate Comparative Table
ASTM/ASME	ISO	USA	JAPAN	BRITAIN	GERMANY		CNS
UNS No.	ISO	AISI	JIS	BS	WERKSTOFF DIN		CNS
S30400	11	304	SUS304	304S31	1.4301	X5CrNi1810	304
S30403	10	304L	SUS304L	304S11	1.4306	X2CrNi1911	304L

Outside Diameter	OD 0.28-1219mm
Thickness	0.08-100mm
Seamless Stainless Steel Pipes	1/8“NB to 32“NB IN
Production Process	Cold Drawn,Bright Anneal.etc
Type	Seamless,welded
Surface	Pickling,Bright；
Price Item	EXW,FOB,CNF,CIF etc
Application	1. Oil and gas equipment 2. Ocean engineering technology 3. Desalination plants 4. Chemical industry 5. Bridges
Ends:	Beveled or plain end, square cut, burr free

Stainless Steel Seamless Pipe Chemical Component:

The EN 1.4301 chemical component

Chemical Composition about stainless steel pipe
Grade	C ≤	Si ≤	Mn ≤	P ≤	S ≤	Ni ≤	Cr ≤
EN 1.4301	0.08	0.75	2	0.045	0.03	8.00-11.00	18.00-20.00
EN 1.4306	0.035	0.75	2	0.045	0.03	8.00-13.00	18.00-20.00

Size table:

Seamless stainless steel pipes

WALL THCKNESS FOR STAINLESS STEEL PIPE &T UBE (ASME B36.10 & B36.19)
DNmm	DNin	φmm	SCH5S	SCH10S	SCH40S	STD	Sch40	Sch60	Sch80s	XS	Sch80	Sch120	Sch140	Sch160	XXS
6	1/8	10.3		1.24	1.73	1.73	1.73		2.41	2.41	2.41
8	1/4	13.7		1.65	2.24	2.24	2.24		3.02	3.02	3.02
10	3/8	17.1		1.65	2.31	2.31	2.31		3.2	3.2	3.2
15	1/2	21.3	1.65	2.11	2.77	2.77	2.77		3.73	3.73	3.73			4.78	7.47
20	3/4	26.7	1.65	2.11	2.87	2.87	2.87		3.91	3.91	3.91			5.56	7.82
25	1	33.4	1.65	2.77	3.38	3.38	3.38		4.55	4.55	4.55			6.35	9.09
32	1 1/4	42.2	1.65	2.77	3.56	3.56	3.56		4.85	4.85	4.85			6.35	9.7
40	1 1/2	48.3	1.65	2.77	3.68	3.68	3.68		5.08	5.08	5.08			7.14	10.15
50	2	60.3	1.65	2.77	3.91	3.91	3.91		5.54	5.54	5.54			8.74	11.07
65	2 1/2	76	2.11	3.05	5.16	5.16	5.16		7.01	7.01	7.01			9.53	14.02
80	3	88.9	2.11	3.05	5.49	5.49	5.49		7.62	7.62	7.62			11.13	15.24
90	3 1/2	101.6	2.11	3.05	5.74	5.74	5.74		8.08	8.08	8.08
100	4	114.3	2.11	3.05	6.02	6.02	6.02		8.56	8.56	8.56	11.13		13.49	17.12
125	5	141.3	2.77	3.4	6.55	6.55	6.55		9.53	9.53	9.53	12.7		15.88	19.05
150	6	168.3	2.77	3.4	7.11	7.11	7.11		10.97	10.97	10.97	14.27		18.26	21.95
200	8	219.1	2.77	3.76	8.18	8.18	8.18	10.31	12.7	12.7	12.7	18.26	20.62	23.01	22.23
250	10	273	3.4	4.19	9.27	9.27	9.27	12.7	12.7	12.7	15.09	21.44	25.4	28.58	25.4
300	12	323.8	3.96	4.57	9.53	9.53	10.31	14.27	12.7	12.7	17.48	25.4	28.58	33.32	25.4
350	14	355.6	3.96	4.78		9.53	11.13	15.09		12.7	19.05	27.79	31.75	35.71
400	16	406.4	4.19	4.78		9.53	12.7	16.66		12.7	21.44	30.96	36.53	40.49
450	18	457	4.19	4.78		9.53	14.27	19.05		12.7	23.83	34.93	39.67	45.24
500	20	508	4.78	5.54		9.53	15.09	20.62		12.7	26.19	38.1	44.45	50.01
550	22	559	4.78	5.54		9.53		22.23		12.7	28.58	41.28	47.63	53.98
600	24	610	5.54	6.35		9.53	17.48	24.61		12.7	30.96	46.02	52.37	59.54
650	26	660				9.53				12.7
700	28	711				9.53				12.7
750	30	762	6.35	7.92		9.53				12.7
800	32	813				9.53	17.48			12.7

Conforms to ANSI B36.19 and ANSI B36.10 standards

Welded Stainless Steel U Bent Tube Bending EN 1.4301 1000mm
