    Sanitary Seamless Stainless Steel Pipe EN1.4404 A316 316L Thick Wall 1000mm

    Ask Lasest Price
    Brand Name : ZHE HENG
    Model Number : EN1.4401
    Certification : BV, PED, ISO9001
    Price : $1000-4200/Ton
    Payment Terms : L/C, T/T, D/P, D/A
    Supply Ability : 1000+
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    Sanitary Seamless Stainless Steel Pipe EN1.4404 A316 316L Thick Wall 1000mm

    Product Description


    Overview:

    EN1.4404 sanitary stainless steel pipe has excellent corrosion resistance, temperature resistance, ultra-low temperature compressive strength and mechanical equipment characteristics.

    EN1.4404The inner and outer surface of the 316L stainless steel pipe will be polished and polished to make the surface of the stainless steel pipe more smooth and luminous, which is to avoid the hydromechanical chemicals outside the pipe to produce wall hanging outside the pipe, prevent environmental pollution and produce outside the pipe obstruction.


    Specification:

    Material Grade

    America StandardS30100,S30200,S30300,S30323,S30400,S30403,S31000,S31008,S31600,S31603,S31635,S31700,S32100
    Japan StandardSUS202,SUS301,SUS302,SUS303,SUS303Se,SUS304,SUS304L,SUS305,SUS316,SUS316L,SUS316Ti,SUS317
    Europen Standard1.431,1.43,1.4305,1.4301,1.4306,1.4303,1.4828,1.4841,1.4845,1.4401,1.4404,1.4571,1.4436,1.4541

    Outside DiameterOD 0.28-1219mm
    Thickness0.08-100mm
    Seamless Stainless Steel Pipes1/8“NB to 32“NB IN
    Production ProcessCold Drawn,Bright Anneal.etc
    TypeSeamless,welded
    SurfacePickling,Bright;
    Price ItemEXW,FOB,CNF,CIF etc
    Application
    1.Food and pharmaceutical
    2.Biological fermentation
    3.Water treatment
    4.Air conditioning refrigeration
    5.Instrument and meter
    6.Pressure vessel
    7.Aerospace
    8.Pipeline installation and other fields;

    Ends:Beveled or plain end, square cut, burr free


    Stainless Steel Seamless Pipe Chemical Component:

    Chemical Composition about stainless steel pipe
    GradeC ≤Si ≤Mn ≤P ≤S ≤Ni ≤Cr ≤
    EN1.44040.0350.7520.0450.0310.00-15.0016.00-18.00

    Size table:

    Seamless stainless steel pipes

    WALL THCKNESS FOR STAINLESS STEEL PIPE &T UBE (ASME B36.10 & B36.19)
    DNmmDNinφmmSCH5SSCH10SSCH40SSTDSch40Sch60Sch80sXSSch80Sch120Sch140Sch160XXS
    61/810.31.241.731.731.732.412.412.41
    81/413.71.652.242.242.243.023.023.02
    103/817.11.652.312.312.313.23.23.2
    151/221.31.652.112.772.772.773.733.733.734.787.47
    203/426.71.652.112.872.872.873.913.913.915.567.82
    25133.41.652.773.383.383.384.554.554.556.359.09
    321 1/442.21.652.773.563.563.564.854.854.856.359.7
    401 1/248.31.652.773.683.683.685.085.085.087.1410.15
    50260.31.652.773.913.913.915.545.545.548.7411.07
    652 1/2762.113.055.165.165.167.017.017.019.5314.02
    80388.92.113.055.495.495.497.627.627.6211.1315.24
    903 1/2101.62.113.055.745.745.748.088.088.08
    1004114.32.113.056.026.026.028.568.568.5611.1313.4917.12
    1255141.32.773.46.556.556.559.539.539.5312.715.8819.05
    1506168.32.773.47.117.117.1110.9710.9710.9714.2718.2621.95
    2008219.12.773.768.188.188.1810.3112.712.712.718.2620.6223.0122.23
    250102733.44.199.279.279.2712.712.712.715.0921.4425.428.5825.4
    30012323.83.964.579.539.5310.3114.2712.712.717.4825.428.5833.3225.4
    35014355.63.964.789.5311.1315.0912.719.0527.7931.7535.71
    40016406.44.194.789.5312.716.6612.721.4430.9636.5340.49
    450184574.194.789.5314.2719.0512.723.8334.9339.6745.24
    500205084.785.549.5315.0920.6212.726.1938.144.4550.01
    550225594.785.549.5322.2312.728.5841.2847.6353.98
    600246105.546.359.5317.4824.6112.730.9646.0252.3759.54
    650266609.5312.7
    700287119.5312.7
    750307626.357.929.5312.7
    800328139.5317.4812.7

    Conforms to ANSI B36.19 and ANSI B36.10 standards

    Sanitary Seamless Stainless Steel Pipe EN1.4404 A316 316L Thick Wall 1000mm

    Sanitary Seamless Stainless Steel Pipe EN1.4404 A316 316L Thick Wall 1000mm


    FAQ:
    Q: Are you a manufacturer or merely a trader?
    A: We are group of companies and owned manufacturer bases and trading company. We specialized in special steel which include alloy structural steel and carbon steel and stainless steel, etc. All material are with high quality and competitive price.
    Q: How do you guarantee the quality of your product?
    A: Firstly, we can provide the certificates from the third party, such as TUV, CE, if you need. Secondly, we have a complete set of inspection system and every process is checked by QC. Quality is the lifeline of enterprise survival.
    Q: Delivery time?
    A: We have ready stock for most of material grades in our warehouse. If the material don't have stock, the delivery lead time is about 5-30 days after receiving your prepayment or firm order.
    Q: What is the payment term?
    A: T/T or L/C.
    Q: Can you provide a sample for our testing before confirm the order?
    A: Yes. We can provide sample to you for approval before you place an order to us. Free sample is available if we have stock.
    Q: Can we visit your company and factory?
    A: Yes, warmly welcome! We can book the hotel for you before you come to China and arrange our driver to our airport to pick you up when you come.
